Description
|
Processor
|
Intel® Xeon® processor E3-1200 product family Intel® Xeon® processor E3-1200 V2 product family Intel® Pentium® G600 and G800 series Intel® Celeron® G400 and G500 series |
|
Operating System
|
Microsoft® Windows Server® 2012 Microsoft Windows® Small Business Server 2011 Microsoft Windows Server 2008 R2 Foundation SP1 Microsoft Windows Server 2008 SP2, x86/x64 (x64 includes Hyper-V®) Microsoft Windows Server 2008 R2 SP1, x64 (includes Hyper-V v2) Microsoft Windows HPC Server 2008 Novell® SUSE® Linux Enterprise Server Red Hat® Enterprise Linux® Virtualization options: Citrix® XenServer® Microsoft Hyper-V, a server role in Microsoft Windows Server operating systems VMware® vSphere® and ESXi™ Red Hat Enterprise Virtualization® |
|
Chipset
|
Intel® C202 |
|
Memory
|
Up to 32GB (4 DIMM slots) 1GB/2GB/4GB/8GB DDR3 up to 1600MT/s |
|
Storage
|
Cabled hard drive options: 2.5″ SATA SSD, SAS (10K) 3.5″ SAS (15K), nearline SAS (7.2K), SATA (5.4K, 7.2K)Maximum Internal Storage: Up to 6TB |
|
Drive Bays
|
Cabled options available: Up to two 3.5″ SAS or SATA drives Up to four 2.5″ SATA SSD or SAS drives |
|
Slots
|
1 PCIe x16 G2 slot |
|
RAID Controllers
|
Internal Controllers: PERC S100 ( software based) PERC S300 (software based) PERC H200 (6Gb/s)External HBAs (non-RAID): 6Gbps SAS HBA |
|
Network Controller
|
One Dual port Broadcom BCM 5716 |
|
Communications
|
Broadcom® NetXtreme® 5709 Dual Port Gigabit Ethernet NIC, Copper, w/TOE PCIe x4 Broadcom® NetXtreme® 5709 Dual Port Gigabit Ethernet NIC, Copper, TOE/iSCI PCIe x4 Broadcom® NetXtreme® II 5709 Quad Port Gigabit Ethernet NIC, Copper, w/TOE/ iSCI PCIe x4 Intel Gigabit ET Dual Port Adapter, Gigabit Ethernet NIC, PCIe x4 Intel Gigabit ET Quad Port Adapter, Gigabit Ethernet NIC, PCIe x4 |
|
Availability
|
Quad-pack LED diagnostic, ECC Memory, add-in RAID, TPM/TCM |
|
Graphics Card
|
Matrox G200eW w/8MB memory |
|
Chassis
|
42.4 H x 434.0 W x 394.3 D (mm) 1.66” H x 17.09” W x 15.52” D (in) |
|
Management
|
BMC, IPMI 2.0 compliant Dell OpenManage™ Unified Server Configurator Lifecycle Controller enabled via optional: iDRAC6 Express, iDRAC6 Enterprise and vFlash |
|
Environmental Operating Conditions
|
Acoustics: Typically configured 3.5″ cable chassis in 23 ± 2 °C ambient Idle: LwA-UL = 5.2 bels; LpA = 40 dBA |
| Power Supply | Single cabled power supply (250W) (80+ SILVER) |
| Optical Drive | DVD Drive, Internal |
